Brixwell Casement Hinge Arm Set, Stainless Steel Material, 5" Link Arm, 7-5/8" Arm Length, Gray Finish - 2 of 2

Shop all Brixwell

Brixwell Casement Hinge Arm Set, Stainless Steel Material, 5" Link Arm, 7-5/8" Arm Length, Gray Finish

Name: Brixwell Casement Hinge Arm Set, Stainless Steel Material, 5" Link Arm, 7-5/8" Arm Length, Gray Finish
Brand: Brixwell
SKU: 1009255645
Price: 38.11 USD
Availability: InStock

undefined out of 5 stars with 0 reviews

$38.11

In Stock

Free & easy returns

Return this item by mail or in store within 30 days for a full refund.

Sold & shipped by DK Hardware Supply LLC

Eligible for registries and wish lists

Save 5% every day

With Target Circle™ Card

About this item

Details

Highlights

Material specification is Stainless Steel for the entire assembly structure.
The exterior surface is treated with a Gray finish for visual presentation.
Link Arm Length is precisely 5" (127mm) for required operational reach.
Overall Arm Length dimension is stated as 7-5/8" (194mm) in documentation.
Upper to Middle Hole Center distance measures 3-7/16" (87mm) accurately.
End Hole Center measurement is specified as 2-1/4" (57mm) for alignment.
Mounting Plate Length dimension is 1-1/2" (38mm) for secure installation base.

Description

This Brixwell Casement Hinge Arm Set is constructed from Stainless Steel material and presents a Gray finish. It is intended for use in mechanical assemblies where precise linkage geometry is required. The overall Arm Length dimension is stated as 7-5/8" (194mm). A key feature is the Link Arm Length, which measures 5" (127mm), defining a specific operational range. For accurate positioning during assembly, the distance between the Upper to Middle Hole Center is specified as 3-7/16" (87mm). Furthermore, the End Hole Center spacing is listed as 2-1/4" (57mm). The base attachment point utilizes a Mounting Plate Length of 1-1/2" (38mm) to ensure stable mounting. These physical attributes define the component's suitability for specific structural requirements. The Stainless Steel composition provides inherent material characteristics appropriate for various operational settings. The finish contributes to the overall aesthetic presentation of the installed hardware.

Specifications

Dimensions (Overall): 1.0 inches (H) x 1.0 inches (W) x 4.27 inches (D)

Weight: 1.0 pounds

Material: Stainless Steel

TCIN: 1009255645

UPC: 192085003653

Origin: imported
