About this item
Highlights
- 2 Ω Stable
- Corrosion Protection
- Water Jet Tested
- Latest Generation D-class
- Salt Fog Tested
Description
General Specs
Channels: 1
POWER SUPPLY
Power supply voltage / fuse: 11 ÷ 15 VDC / 3 x 30 A
Idling current (power ON/OFF) 0.8 A / 1 mA
Consumption @ 2 Ω, 14.4 VDC (Max Musical Power): 45 A
Remote In: 7 ÷ 15 VDC - 1 mA
ART: Automatic Remote Turn-On/Off with Speaker-In
AMPLIFIER STAGE
Distorsion - THD (100 Hz @ 4 Ω): 0.25%
Bandwidth: 10 ÷ 500 Hz
S/N Ratio (A weighted @ 1 V): 100 dB
Damping factor (100 Hz @ 4 Ω): > 100
Pre-In sensitivity: 0.2 ÷ 5 VRMS
Speaker-In sensitivity: 0.8 ÷ 20 VRMS
Load impedance (MIN): @ 1 Ch: 2 Ω
Max size (mm / in.): 315 x 190 x 50 / 12.40 x 7.48 x 1.97
Weight (kg / lb.): 3 / 6.61
Adjustable Crossovers: yes
Output Power
Output Power (RMS) @ 14.4 VDC, THD 1%
1 Ch: 600 W x 1 (4 Ω)
1 Ch: 1100 W x 1 (2 Ω)
Output Power (RMS) @ 14.4 VDC, THD 10%:
1 Ch: 740 W x 1 (4 Ω)
1 Ch: 1240 W x 1 (2 Ω)
CEA 2006-A Ratings:
RMS Power (4 Ω, ≤1 %THD + N, 14.4 V): 600 W x 1 Ch
S/N Ratio (ref. 1 W output): 80 dBA
Total Power RMS 1240 W
INPUTS / FILTERS
INPUTS: PRE IN / SPEAKER IN
Pre out Hi-Pass: 50 ÷ 250 Hz @ 12 dB/Oct.
Filters FULL: Yes
Lo-Pass: 50 ÷ 250 Hz @ 24 dB/Oct.
SUBSONIC (on/off): 25 Hz @ 24 dB/Oct.
BOOST 50 Hz (adjust): (0 ÷ 6) dB
PHASE(adjust): (0 ÷ 180) deg
Remote Volume Control (adjust): (-50 ÷ 6) d
Dimensions (Overall): 1.97 inches (H) x 7.48 inches (W) x 12.4 inches (D)
Weight: 5.0 pounds
Electronics Condition: New
Wireless Technology: No Wireless Technology
Battery: No Battery Used
Warranty: 1 Year Limited Warranty. To obtain a copy of the manufacturer's or supplier's warranty for this item prior to purchasing the item, please call Target Guest Services at 1-800-591-3869
TCIN: 88662853
UPC: 8018823138390
Origin: made in the USA or imported
