Cerwin Vega VCU81 Vega Series 1‑Channel Class‑D Mono Amplifier – 600 W RMS @ 1 Ω, 400 W RMS @ 2 Ω – Compact Micro Amp with Bass Control Knob
$329.99 when purchased online
Target Online store #3991
About this item
Highlights
- True RMS Power for Serious Bass – Delivers 600 W RMS @ 1 Ω, 400 W RMS @ 2 Ω, and 240 W RMS @ 4 Ω, driving your subwoofers deeper and harder with clarity
- Compact “Micro” Footprint – Measuring just under 9″ long, this slim Class D mono amp fits virtually anywhere—making it ideal for stealthy installs in cars, UTVs, or tight spaces.
- Remote Bass Control for on-the-fly tuning – Includes wired bass knob so you can adjust sub-levels from your seat without touching the amp.
- Built to Last – Features high-efficiency IR chipset, conformal-coated 4-layer PCB, water-resistant design, and robust heatsink platform for reliable performance in harsh environments
- Optimized for All Setups – Accepts both high- and low-level inputs up to 12 V, equipped with 40–400 Hz LPF crossover, selectable remote turn‑on modes (REM/DC/VOX), and boosted RFI protection for clean, distortion-free audio
Description
The Vega Series Amplifiers have solidified their place as the backbone of the Cerwin-Vega Mobile brand, delivering unrivaled performance in a sleek, compact package. Don’t be deceived by their streamlined design—these amplifiers pack a punch with monstrous power output to drive your system to its fullest potential.
Innovation Meets Power
Updated High-Efficiency Full Range Digital Topology: Experience exceptional sound clarity with maximum energy efficiency.
Enhanced Power IR Digital Chipset: Engineered for stability and precision, ensuring consistent performance under any condition.
Engineered for Durability
Conformal-Coated 4-Layer PCB: Protected against moisture and environmental wear for long-lasting reliability.
Water-Resistant Design: Built to withstand the rigors of the road, wherever your journey takes you.
Specifications
POWER RATING
RMS Power (1Ω): 500W
RMS Power (2Ω): 300W
RMS Power (4Ω): 175W
POWER SUPPLY
Power Supply: Full PWM
Power Supply Threshold: 10.0V-17.0V (DC)
Idle Current: (0.7A)
DISTORTION
THD 4 (1KHz @4Ω): 0.05%
S/N Ratio (A weighted @1W): -85 dBA
S/N Ratio (A weighted @FP): -101.1 dBA
INPUT SENSITIVITY
Low Input Level: 200mV-10.0V
High Input Level: 200mV-10.0V
INPUT IMPEDANCE
Low Input Level: 20 KΩ
High Input Level: 20 KΩ
OUTPUT STAGE
Output Impedance: 0.011Ω
Damping Factor (50Hz @ 4Ω): >250
Bandwidth (-3dB): 10Hz-35KHz
CROSSOVER (-12/-24 dB/Oct)
Variable Low-Pass: 40Hz-400Hz
Variable Sub-Sonic: 10Hz-55Hz
FUSE RATINGS
ATC: 25A
DIMENSIONS
L x W x H: 7.7”x 4.02”x 1.4” (195.6mm x 102mm x 36mm)
FEATURES
Full Range Class D IR Chipset
DirectFET Power Mosfet Output Stage
SMD Technology on 4-Layer PCB Board
Water Resistant Conformal PCB Board Coating
1-year Manufacturer's Warranty
Dimensions (Overall): 18.0 inches (H) x 8.0 inches (W) x 14.0 inches (D)
Weight: 10.0 pounds
Electronics Condition: New
Wireless Technology: No Wireless Technology
Battery: No Battery Used
Warranty: 1 Year Limited Warranty. To obtain a copy of the manufacturer's or supplier's warranty for this item prior to purchasing the item, please call Target Guest Services at 1-800-591-3869
TCIN: 1003299801
UPC: 847169044519
Origin: made in the USA or imported
The above item details were provided by the Target Plus™ Partner. Target does not represent or warrant that this information is accurate or complete. On occasion, manufacturers may modify their items and update their labels.
We recommend that you do not rely solely on the information presented. If you have a specific question about this item, you may consult the item's label, contact the manufacturer directly or call Target Guest Services at 1-800-591-3869.
Shipping details
Estimated ship dimensions: 14 inches length x 8 inches width x 18 inches height
Estimated ship weight: 10 pounds
